The Ultimate Guide to Lamborghini Gallardo Superleggera Scorpius Wheels: Engineering, Fitment & Custom Options
The Lamborghini Gallardo Superleggera stands as one of the most iconic raw V10 supercars ever engineered in Sant'Agata. Central to its lightweight track setup is the iconic 10-spoke Scorpius wheel. Engineered specifically to shed rotating unsprung mass while enduring extreme cornering loads, the Scorpius design remains the aesthetic and dynamic benchmark across the entire Gallardo generation.
Commissioning a set of Lamborghini Gallardo Superleggera Scorpius Wheels provides high-strength monoblock forging, precision OEM fitment, and custom diameter configurations for both standard and high-output V10 builds.
1. Monoblock Metallurgy: Reducing Unsprung Rotational Inertia
In mid-engine supercar engineering, shedding mass from the wheels yields significantly greater dynamic performance gains than removing static weight from inside the cabin. Rotational inertia governs how rapidly a vehicle accelerates, decelerates, and changes direction.
Key Engineering Advantages:
- 6061-T6 Aircraft-Grade Aluminum: Forged under immense hydraulic pressure to align molecular grain structure, providing extreme tensile strength with minimal wall thickness.
- Turn-In Precision: Lightening the front hubs reduces gyroscopic forces at high speeds, sharpening turn-in response through the steering rack.
- Suspension Compliance: Lower unsprung mass allows the double-wishbone suspension and dampers to react faster over road undulations, preserving tire contact patches under hard cornering.
2. Technical Specifications & OEM Factory Dimensions
Maintaining original factory offsets ensures zero fender scrub, precise scrub radius geometry, and proper clearance across multi-piston Brembo calipers.
📊 Factory OEM Scorpius Wheel Specification Matrix
| Engineering Vector | Front Wheel Specification | Rear Wheel Specification |
| Wheel Diameter & Width | 19 x 8.5 Inches | 19 x 11.0 Inches |
| Factory Offset (ET) | ET 41.9 | ET 55.3 |
| OEM Part Numbers | 400601025AK |
400601025AL |
| PCD / Bolt Pattern | 5 x 112 mm | 5 x 112 mm |
| Hub Center Bore | 57.1 mm Hub-Centric | 57.1 mm Hub-Centric |
| Brake Package Clearance | Clears 365mm Steel Rotors | Clears 380mm Carbon Ceramic Rotors |
3. Wheel Configurations & Global Pricing Matrix
Whether preserving original factory 19-inch proportions or creating a modern 19/20-inch or 20/21-inch staggered stance, each set is custom-machined from forged billet stock to meet individual build requirements.
💰 Complete Set Pricing Breakdown (USD)
| Wheel Size Configuration | Stance Profile | Complete Set Pricing |
| 18" Complete Set | Track / Motorsport Classic | $5,000 USD |
| 18" / 19" Staggered Set | Period-Correct Performance | $5,500 USD |
| 19" Complete Set | Factory OEM Gallardo Spec | $6,000 USD |
| 19" / 20" Staggered Set | Modern OEM+ Stance | $6,500 USD |
| 20" Complete Set | Modern Flush Fitment | $7,000 USD |
| 20" / 21" Staggered Set | Aggressive Widebody Fitment | $7,500 USD |
| 21" Complete Set | Show / Custom Profile | $8,000 USD |
| 21" / 22" Staggered Set | Extended Diameter Stance | $8,500 USD |
| 22" Complete Set | Modern Concave Concept | $9,000 USD |
| 23" Complete Set | Ultra-Custom Specification | $10,000 USD |
| 24" Complete Set | Executive Custom Build | $11,000 USD |
4. Vehicle Compatibility & Brake System Integration
The Scorpius monoblock wheel profile fits across all generations of the V10 Gallardo platform and select modern successors:
- Lamborghini Gallardo LP530-4 Superleggera
- Lamborghini Gallardo LP570-4 Superleggera / Edizione Tecnica
- Lamborghini Gallardo LP560-4 (Coupe & Spyder)
- Lamborghini Gallardo LP550-2 (Valentino Balboni & Coupe)
- Lamborghini Gallardo 5.0 (2004–2008 First Generation)
- Lamborghini Huracán Platform (Custom Staggered Configurations)
Brake Clearance Assurance
Factory inner-barrel dimensions clear both standard steel braking systems and factory or aftermarket OEM+ Carbon Ceramic Brake (CCB) packages without requiring wheel spacers or fender roll modifications.
5. Bespoke Finishes & Production Protocol
Every wheel set is commissioned upon request to guarantee perfection and structural consistency:
- Custom Finish Options: Select from Factory Silver, Satin Black, Gloss Black, Titanium Gray, or custom anodized metallic shades.
- Production Timeframe: Precision forging, CNC machining, and multi-stage powder coating require an estimated 8 to 10 weeks.
- Global Express Delivery: Fully insured global freight direct to your residential address or preferred installation facility.
Order Your Custom Forged Scorpius Set
Revisiting original Superleggera dynamics or upgrading a standard Gallardo platform starts with precision-engineered forged wheels.
Submit your vehicle identification number (VIN) at checkout to ensure precise offset and brake setup alignment. Visit our Players Club Cars eBay store today to configure your bespoke set of Lamborghini Gallardo Superleggera Scorpius Wheels.
